EQUIPMENT
Stanmore Equipment is an authorized JLG dealership. JLG® engine powered articulating boom lifts give you the extra reach you need to work over and around obstacles on the job site. Offering exceptional outreach, high capacity, versatile performance, and easy maintenance. An articulating lift provides you with access to those hard-to-reach places.
Contact us at 1-855-955-LIFT (5438) or send us an email to sales@stanmoreequipment.com
Platform HeightUnrestricted Platform Capacity Outreach
45ft - 13.72m550 lb - 249 kg25ft - 7.62m
Platform Height Horizontal Outreach Up and Over Height Swing Platform Capacity - Restricted- UnrestrictedPlatform Size Platform Rotator Jib Range of Articulation Weight Ground Pressure Drive Speed Gradeability 2WD Gradeability 4WDTurning Radius - Inside/Outside2WS 4WS
60 ft - 18 m 39 ft - 12 m 26 ft - 8 m 360 Degrees Continuous 1000 lb - 450 kg 500 lb - 227 kg 30 x 72 in. - 0.76 x 1.83 m 180 Degrees Hydraulic 4 ft - 1.24 m 145 Degrees (+76, -69) 21,640 lb - 9,816 kg 77 psi - 5.5 kg/cm2 4.25 mph - 6.84 km/hr 30% 45% 11 ft - 17 ft 7 in 5 ft 6 in - 1.68 m
